How to Assign a Switch to Control Dual Rate on RC6GS V3/RC4GS V3?

How to Assign a Switch to Control Dual/Triple Rate on RC6GS V3/RC4GS V3? Take RC6GS V3 as an example. Power RC6GS V3 on. Long press Exit and Enter button at the same time to enter the setting page. -- No.13 D/R DUAL RATE. DUAL RATE can reduce the travel amount of a servo. SW means Switch. You can assign a switch to control DUAL RATE. It can be set to NULL, SWA, SWB, SWC, SWD or their lock modes LK-A, B, C, D. If you assign 3 position switch, such as SWB or SWC to control DUAL RATE , you can set 3 different travel amounts. If you assign SWA/D, LK-A/D to control DUAL RATE , 2 different travel amounts can be switched. If SW is set to NULL, DUAL RATE will keep the current values. The VALUE below means the travel amount of the servo, which defaults to 100. It can be set from 0, the minimum travel amount, to 100, the normal travel amount. You can adjust travel amount of steering, throttle, channel 3, 4, 5, 6, 7. Take LK-D as an example in this video. LK-D is the lock modes of SWD. (For the difference of SWD and LK-D, check this tutorial link in our channel:    • LK-A/LK-D Button Setup in RadioLink RC6GS ...  ) Set SW to LK-D. Press SWD and the position of SWD is shown in the right corner of the screen. UP-DOWN. Push SWD to UP, keep all channels the normal travel amount, that is 100 by default. Push SWD to DOWN, set small travel amount for all channels. Like 80. The setting is done. Press SWD, 100. the normal travel amount. Press SWD again, 80. the small travel amount. For more details of RC6GS V3: https://www.radiolink.com/rc6gsv3 Purchase link of RC6GS V3: https://www.radiolink.com/rc6gsv3_whe... You can send mails to after_service@radiolink.com.cn if you have any questions during using our products.
