SIGMAXIM Drawing Builder Application for Creo 2026

SIGMAXIM Drawing Automation - DRAWING BUILDER Application Creating drawings in Creo can be time-consuming and repetitive—especially when working with complex parts and assemblies. To address this, SIGMAXIM has developed the Drawing Builder, a suite of applications that automates and standardizes drawing creation in Creo. In this video, we’ll walk through each application in the Drawing Builder Suite and show how they streamline the drafting workflow.| Create Drawing – Quick Drawing Setup The Create Drawing application helps users quickly create a drawing using the correct format for the model currently displayed on screen. Place Views – Standardized View Placement The Place Views application allows users to add a predefined set of drawing views with just a few clicks. Standard views such as front, top, side, and isometric are placed automatically according to company standards. Create / Modify Views – Full Control Over Drawing Views With Create / Modify Views, users can create new views or edit existing ones directly from a single interface. The tool supports general, projection, section, and detail views, making it easy to refine drawings as designs evolve. Views can also be deleted or updated without navigating through multiple Creo menus. Place Dimensions – Faster, Cleaner Dimensioning Dimensioning is one of the most time-consuming parts of drawing creation. The Place Dimensions application simplifies this by automatically displaying or creating dimensions on selected drawing views. Place BOM – Automated Bill of Materials For assembly drawings, the Place BOM application automatically inserts a bill of materials. The BOM is generated based on the assembly structure, ensuring accuracy and consistency with the model data. This removes the need for manual table creation and reduces the risk of mismatched information. Create Notes – Standardized Drawing Notes The Create Notes application allows users to insert predefined notes directly from a database. This ensures commonly used notes are consistent across drawings and eliminates the need to retype standard text. It also helps organizations enforce drafting standards effortlessly. Delete Drawing Items – Clean and Efficient Editing As designs change, drawings often need updates. The Delete Drawing Elements tool enables users to quickly remove views, dimensions, notes, or tables from a drawing. This provides a fast and controlled way to clean up drawings without manually selecting each element. Export Drawing – Easy Output for Downstream Use Once the drawing is complete, the Export Drawing application makes it easy to generate output files. Drawings can be exported to formats such as DWG, PDF, and DXF, supporting manufacturing, review, and collaboration needs. This ensures drawings are ready for downstream use with minimal effort. Drawing Wizard – End-to-End Drawing Automation The Drawing Wizard is designed to create a complete drawing in one seamless process. With a single workflow, it creates the drawing, then generates views, applies dimensions, inserts notes, and adds a bill of materials where applicable, and finally exports the drawing at the end. For more information, contact SIGMAXIM at info@sigmaxim.com.
