Luminous Hybrid Inverter TX Installation

Watch this video for some expert advice on how you can install transformer based Hybrid Inverter by following these simple steps 1. Three types of input power are given in Hybrid Inverter: Solar, Battery & Grid 2. Tools used for Hybrid Inverter Installation: Digital Clamp Meter, wire cutter, wire stripper, Reversible screw driver, Line tester, Insulation gloves and Shoe cover 3. Wiring: Do wiring as per correct wire gauge so that the system performs well without any interruption 4. Connection Procedure: Battery Connection Solar connection Grid Connection Load Connection 5. Grid input neutral and Load output neutral should not be common. Both neutral should be separate 6. For 5kVA Hybrid Inverter, there are two types of outputs: Line Out for normal appliances and Line Out for AC which is for heavy appliances and both outputs will have common neutral 7. Switching on the system: First switch on Battery MCB, then Solar MCB, Main MCB and Output MCB respectively 8. Configuring Hybrid system: Follow setup steps as per Solar PCU (refer PCU installation video) Setup Grid Feed Mode by allowing feed in GFM Current Settings Hybrid Inverter is ready for operations! Luminous Power Technologies is a powerful and trustworthy brand with a wide range of innovative products in the power backup, home electrical and residential solar space that covers Inverters, Batteries, Solar solutions to home electrical offerings such as Fans, Modular Switches and LED lighting. Visit us at - https://www.luminousindia.com/ Follow us on: Facebook-   / myluminous   Instagram-   / luminous_of.  . Twitter-   / myluminous   LinkedIn -   / lumin.  .
