The simplest way to make a quality HV (High Voltage) source from a PC power supply

This project is sponsored by PCBWAY https://www.pcbway.com/ This time I will present you how to make a quality High Voltage source in a very simple way. For this purpose I will use a old PC power supply, but it can also be used new one, whose price is very low, in the range of ten dollars due to mass production nowadays. During the testing I will use several different power supplies with different defined power and brands. Usually, for HV experiments is used so-called ZVS driver, but damage to the mosfets often occurs due to its low efficiency. I made this device as a basis for future projects related to High Voltage, because it is compact, easy to make, galvanically isolated from the mains and also stable during long-term operation. SAFETY NOTE: Please do not attempt to recreate the experiments shown on this video unless you are familiar with High Voltage Safety Techniques! Direct Current even above 60V maybe lethal, even when the AC supply voltage has been disconnected due to the stored energy in the capacitors. Detailed description, instructions, and pictures at: https://www.hackster.io/mircemk/the-s... Chapters: 0:07 Short Demo 1:43 Description 2:34 Schematic diagram 4:06 Parts 4:50 Power On switch 5:33 Modifying 7:46 First PSU 8:05 Second PSU 8:20 Third PSU 8:52 Fourth PSU 9:25 On Oscilloscope 9:53 Conclusion If you like my job buy me a coffee: https://ko-fi.com/mircemk If you are interested in this area, look at the Playlist with all my High Voltage projects at:    • High Voltage   Visit my Youtube Channel for more Projects , DIY and How To Make videos:    / mirkopavleskimk   by mircemk SUBSCRIBE LIKE AND SHARE !!!! Thanks for your Support ! #arduino #PSU #highvoltage #PCBWay
