Cabinet Vision - Swapping hinges via UCS

In this video I demonstrate how to change hinges with a UCS based on a variety of different conditions for blind panel/extended end cabinets when the doors are set to be a pair. PDF of the document I referenced during stream can be downloaded here: https://drive.google.com/file/d/1jCAK... Bi-weekly live streams on Twitch every other Friday at 10:00 AM PDT/PST (GMT-7/GMT-8):   / bward9001   If you appreciate what I'm doing and would like to support future videos, buy me a coffee or simply donate to the cause: https://tinyurl.com/2tnxxrmm 00:00 Introduction 07:55 Use an outline to prepare 20:20 Let's get into it 27:25 Blind Panel Hinge Model 29:45 Filtering for right extended ends 36:00 Changing the right door hinge 40:55 Changing the left door hinge 48:00 Checking off your condititions to address list 50:25 Filtering for left extended ends 52:15 Tidying things up a little 52:55 Formatting your UCS for readability and upkeep 1:02:11 Oops! My exit was not written correctly 1:04:56 Getting rid of the wrong hinge plates 1:07:15 How to climb up THEN down the Object Tree 1:17:20 Adding the right (invisible) hinge plates 1:26:00 Programming joke 1:27:50 Checking my Hardware
