High Speed Roll to Roll Slitting Machine | RK-HS-320

01. MODEL: HS – 320 HIGH SPEED LABEL SLITTING & REWINDING MACHINE • Maximum Paper Width: 320 mm • Unwinding Unit Roll ø600MM Maximum with 3” Manual Shaft • Electronic Web Guide for Paper Movement on Unwinding Side • Unwinding Unit Tension Controlled by Mechanical Brake System • Slicing Table for Paper joint • Both Rotary & Normal Shear Blade Slitting attachment • Air Blower System for Waste Trimming Collection • Label Counting Sensor • Up & Down Rewinding System (Rewinding Roll ø450MM Max) • Rewinding Unit Tension Controlled by Mechanical Clutch System • Facility for Both Forward & Reverse Rewinding Direction with Switch Control • Facility for 1”,1.5”,3” Core on Rewinding with Selection on Touch Screen (Easy of Core Change Setting) • Full Touch HMI Screen for Easy of Operation & Setting • 1 HP AC Variable Speed Control Motor for Nip Roll / Slitting Unit • 1 HP AC Variable Speed Control Motor for Rewinding Unit • Both Motor Operated by Individual Variable Frequency Drive • Meter Counter & Label Counter with Auto Stop Control • Machine Controlled By Electronic PLC System • Rewinding Core Size 1”, 1.5”, 3” Changeable with collator (Each 2 Pcs) • Machine Mechanical Speed – 100 m/min • Power Consumption - 2 HP Single Phase • Height 4.5 Ft, Width.3.5 Ft, Length 6 Ft
