Upgrade Classic Tivoli Audio Model One with Bluetooth, Smart Wifi Outlet, and FM Antenna.

In this video, I will add a custom 3D print enclosure to the classic original Tivoli Audio Model One for Bluetooth connectivity. But this can apply to any active speaker or vintage audio system that uses a DC power supply. The custom enclosure is a better way to add Bluetooth connectivity. By integrating the power supply, It gives neater and well-organized wiring with fewer wires. However, it is possible to cause ground loop noise, which is a common issue in some systems. I also included a simple solution to fix it in this video. I also add a Smart Wifi outlet and 75-Ohm FM Antenna. All these upgrades allow you to enjoy wireless music from your old device and make it more convenient to use. Project Page & Wiring Diagram: https://simplymaker.net/3d-printing/t... ► 3D PRINT PARTS ● Tavoli Audio Model One Bluetooth Module Enclosure: https://www.printables.com/model/4840... ► COMPONENTS FOR THIS PROJECT ● DIY Bluetooth Receiver Module (VH-314 or XFW-BT): https://s.click.aliexpress.com/e/_DC5... ● B1205S-1W fixed voltage ground isolator: https://s.click.aliexpress.com/e/_Dn0... ● 6mm SPDT Slide Switch (2 Positions 3 Poles): https://s.click.aliexpress.com/e/_DnD... ● DC Power Socket 5.5x2.1mm: https://s.click.aliexpress.com/e/_DD3... ● DC Power Jack 5.5x2.1mm: https://s.click.aliexpress.com/e/_DD3... ● 3.5mm 3 Pole Audio Jack: https://s.click.aliexpress.com/e/_DBF... –Optional Components ● 1N4007 Diode 1A: https://s.click.aliexpress.com/e/_DBF... ● Tuya WiFi Smart Plug 10A: https://s.click.aliexpress.com/e/_DDB... ● 75-Ohm FM Indoor Antenna 7 sections 75 cm: https://s.click.aliexpress.com/e/_DF0... ● DC 5.5x2.1 Male 90 degrees extension Cord: https://s.click.aliexpress.com/e/_Dmu... ● Mini DC-DC 2A Step-Down Converter: https://s.click.aliexpress.com/e/_DEC... ● B0505S-1W fixed voltage ground isolator: https://s.click.aliexpress.com/e/_Dn0... ► ELECTRONIC SUPPLY AND FASTENING ● Brass Hot Melt Inset Nuts SL-type (M3xD5xL4): https://s.click.aliexpress.com/e/_Dm7... ● M3 x 12mm Button Head Screws (X3): ● M3 x 20mm Button Head Screws (X1): ● M2.5 x 5mm Button Head Screws (X2): ● M2 x 5mm Button Head Screws (X2): ● Shield wire and 24 AWG wires: ► TOOL I USE ● UNI-T UT89X Digital Multimeter: https://s.click.aliexpress.com/e/_DDb... ● ARROWMAX Electric Cordless Screwdriver (SES): https://s.click.aliexpress.com/e/_DmJ... ● PG8018LCD Electronic Hot Air Gun: https://s.click.aliexpress.com/e/_DmH... ● T12-TR Portable Soldering Iron: https://s.click.aliexpress.com/e/_DmT... ● DIY Makita T12 Soldering Station: https://simplymaker.net/3d-printing/p... ► FILAMENT USE IN THIS PROJECT ● eSun PLA+: https://s.click.aliexpress.com/e/_AkrgFH ► SUBSCRIBE TO THE CHANNEL: http://shorturl.at/gikA4 ► FACEBOOK:   / simplymakerth   ► INSTAGRAM:   / simplymakerth   ► WEBSITE: https://www.simplymaker.net 00:00 Introduction 00:35 External Bluetooth Overview 01:32 Tivoli Model One 02:00 Mini Bluetooth 5.0 Module 03:20 Component List 05:02 Prepare the Enclosure 07:08 Connector Wiring 10:07 Bluetooth Module Wiring 13:31 Testing 14:12 Smart Wifi Switch 15:23 75-Ohm FM Antenna 16:18 Conclusion DISCLAIMER: This video and description contain affiliate links that support our channel. We are not responsible for any losses, damage, or injury in connection with the use of our content. Testing Video from: Travel | Relax | Listen -    / @travelrelaxlisten
