Takeuchi TB335R Compact Excavator (2024) Exterior and Interior

2024 Takeuchi TB335R Compact Excavator seen from outside and inside. Operational mass 3,760 kg. Noise level 93.0 dB (A). Turning speed 9.0 U/min. Low moving speed 3.0 km/h. High moving speed 4.1 km/h. Max inclination 25°. Angle of movement of arrow 70°/55°. Engine is Kubota V1505. Nominal engine power 18.2 kW (24.8 hp) at 2,300 rpm. Engine displacement 1,498 cm³. 4 cylinders. Cooling system displacement 12.5 l. Oil tank volume 6.7 l. Hydraulic reservoir capacity 28.4 l. Fuel tank 43.5 l. P1, P2 Variable Displacement Pump flow Rate 42.6 l/min. Relief Pressure 24.5 MPa. P3 Gear Pump Flow Rate 21.9 l/min. Relief Pressure 20.6 MPa. Service Port 1 Flow Rate 64.4 l/min. Hydraulic Pressure 21.0 MPa. Service Port 2 Flow Rate 21.9 l/min. Hydraulic Pressure 20.6 MPa. Service Port 3 Hydraulic Pressure 20.6 MPa. Service Port 4 Flow Rate 21.9 l/min. Hydraulic Pressure 20.6 MPa. Max digging depth 3,305 mm. Max digging height 4,845 mm. Max vertical digging depth 2,565 mm. Max offload height 3,430 mm. Max range for digging at ground level 5,305 mm. Max digging range 6,430 mm. Max range of vertical digging 3,655 mm. Gauge width of the tower 1,625 mm. Cab width 1,040 mm. Width of base plate of chain 300 mm. Clearance 295 mm. Gauge width of undercarriage part 1,740 mm. Gauge length of chains 2,215 mm. Transport length 4,870 mm. Paddle height 395 mm. Paddle width 1,740 mm. Total height 2,490 mm. The machine was shown at ATEST Expo 2024.
