DIAGNOSTIC EVENT MANAGER | DEM | DEBOUNCE MECHANISM | AUTOSAR

This Video Covers the DEM(Diagnostic Event Manager ) Overview and debounce mechanism . DEM module is responsible for diagnostic event processing and storing of event related data to memory and read event related data from memory and provide information to DCM module There are three types of event debouncing mechanism provided by DEM module. 1. Time Based Debouncing 2. Counter Based Debouncing 3. Monitor Internal Debouncing It also covers the basic about DTC Status Bytes , Operation Cycle and Event Aging. DTC Status Bytes: Bit 0 : Test Failed Bit 1 : This Failed This Operation Cycle Bit 2 : Pending DTC Bit 3 : Confirmed DTC Bit 4 : Test Not Completed Since Last Clear Bit 5 : Test Failed Since Last Clear Bit 6 : Test Not Completed This Operation Cycle Bit 7 : Warning Indicator Requested AUTOSAR PLAYLIST LINK :    • AUTOSAR
