DIY LED Aircraft Strobe Light Circuit using a PC817 Optocoupler In this project, I’ll show you how to create your own LED Aircraft Strobe Lights at home using simple electronic components. These lights are designed to replicate the effect of a real aeroplane strobe light and aircraft beacon light, giving your DIY projects a realistic aviation touch. Whether you’re interested in building a plane strobe light for hobby use, experimenting with aircraft strobes, or just want to learn how a strobe light on aircraft works, this tutorial will guide you step by step. We’ll wire components together to produce a blinking pattern that looks just like airplane strobe lights and wingtip strobe lights used in real aviation. What’s even more exciting is that this aircraft strobe light project can also be adapted for fun uses like installing aircraft strobe lights for bike, aircraft strobe lights for car, or even creative DIY decoration. With just a few changes, you can turn this into a led aircraft strobe setup that looks amazing in the dark. By the end of this video, you’ll understand how to design, solder, and power a simple yet effective airplane beacon light or airplane strobe system. It’s an easy and budget-friendly project for electronics beginners and hobbyists who want to explore aviation-style lighting. Whether you’re fascinated by strobe aircraft systems or simply looking for a creative DIY light project, this tutorial is for you. Don’t forget to like, share, and subscribe for more exciting electronics builds! Today, I will build a DIY LED aircraft strobe light circuit using a PC817 optocoupler. The PC817 is a very useful electronic component that provides isolation between different parts of a circuit and is often used in switching and control systems. First, I will carefully straighten all four pins of the optocoupler so that it can be easily placed and soldered on the board. Straight pins ensure better soldering and stronger connections. Next, I will apply a small amount of solder to each pin. Pre-tinning the pins with solder makes the final assembly quicker and ensures solid electrical contact. Now, this is a 220µF electrolytic capacitor, which will act as a timing element in our circuit. I will solder its negative leg to the first pin of the optocoupler, and its positive leg to the third pin. This capacitor helps in charging and discharging, which creates the blinking or strobe effect for the LED. Next, I will solder a 1kΩ resistor between the positive leg of the capacitor and the second pin of the optocoupler. This resistor controls the current flow into the optocoupler, protecting it from excessive current and ensuring stable operation. After soldering, I will trim the extra pins for a neat and professional look. Now, let’s move to the LED. This will act as the strobe light itself. I will bend the negative pin of the LED, trim it short, and then bend the positive pin for proper alignment. I will solder the negative pin of the LED directly to the fourth pin of the optocoupler. This connection allows the LED to blink whenever the optocoupler switches. Next, I will take a 10kΩ resistor and solder it between the first pin of the optocoupler and the positive pin of the LED. This resistor further controls the current supplied to the LED, ensuring that it doesn’t burn out and blinks at the correct brightness. Once again, I’ll trim the extra pins for safety and neatness. Now it’s time to add power connections. I will solder the positive wire of the circuit to the positive pin of the LED, and the negative wire to the second pin of the optocoupler. This ensures proper powering of both the optocoupler and the LED in the circuit. aeroplane strobe light, aircraft strobe light, airplane strobe lights, led aircraft strobe lights, aircraft beacon light, aircraft strobes, aircraft strobe light for bike, aircraft strobe lights for bike, aircraft strobe lights for car, airplane beacon light, airplane strobe, plane strobe light, strobe aircraft, led aircraft strobe, strobe light on aircraft, wingtip strobe lights Finally, I will bring in a 9V battery to power the project. As soon as I connect the battery, the LED begins to blink automatically, just like aircraft strobe lights. The capacitor charges and discharges repeatedly, while the resistors and optocoupler control the blinking cycle, giving a rhythmic strobe effect. ✨ This simple project beautifully demonstrates how timing circuits work using capacitors, resistors, and optocouplers. The blinking LED effect can be used not only for aircraft strobe simulations, but also in decorative lighting, DIY night lamps, warning indicators, science projects, and even as a fun way to learn about electronics. 👉 If you want to make your DIY projects more exciting, you can even try experimenting with different resistor and capacitor values to change the blinking speed of the LED.
