CINCINNATI R75 PRODUCTION (ID/OD) CYLINDRICAL GRINDER

CINCINNATI R75 PRODUCTION (ID/OD) CYLINDRICAL GRINDER CONTACT: +91-9834813425 / info@corelmachine.com Category: CYLINDRICAL GRINDERS Reference No.: 400188 Capacity: Ø254 × 787 mm Year of Construction: 1974 Video Link:    • CINCINNATI R75 PRODUCTION (ID/OD) CYLINDRI...   Technical Specification: Additional Details: Cincinnati Universal Cylindrical Grinder Model: 254 × 787 R75 Year: 1974 Standard Specifications Cincinnati Universal Cylindrical Grinder Model: 254 × 787 R75 Standard Specifications Capacity Swing over table: 254 mm Distance between centers: 787 mm Table Maximum table travel: 787 mm Infinitely variable traverse speeds: 2 – 240 mm/min Table traverse per rev. of hand wheel: 2.5 – 12.7 mm Infinitely variable table tarry: 0 – 6 sec. Maximum swivel of table: ±10° Headstock Infinitely variable spindle speeds: 60 – 480 RPM Swivel range: 0 – 90° Diameter of bore in spindle: 36 mm Center taper in spindle: #13 Jarno Machine center (with adapter): #8 Jarno Wheel Head Rapid advance stroke: 51 mm Manual in-feed (per hand wheel rev. on dia.): 1.27 mm Auto pick feed on dia. (8 steps): 0.005 – 0.04 mm Auto in-feed (max stock removal on dia.): 2 mm Hand lever pick feed on dia.: 0.0025 mm Swivel (upper & lower): ±90° Grinding wheel size: 305 mm dia. × 38 mm width × 127 mm bore Wheel speed: 6,500 SFM (approx. 33 m/s) Machine Data Approx. weight: 3,630 kg Approx. dimensions (L × W × H): 2057 × 1829 × 1448 mm Equipped With Double swivel wheel head design Dual live/dead work head spindle 4 H.P. 3/60/230–460 volt wheel head motor Max. work weight between centers (without steady rest): 75 kg Hydraulic operation featuring: Power table traverse Automatic in-feed
