Setting Up an IES Visual Analysis Report Table

This video describes how to set up a customized report table in IES Visual Analysis. With a custom table, it's very easy to see the maximum deformations and stresses in a structure. The custom table can be saved as a template for future analyses. This tutorial is using the educational version of Visual Analysis 18. Note that most of these tables will default to "Extreme Rows" as shown in faded grey above the table. To see all members, click on the table, and to to the Project Manager and the "Selected Table" tab. There, make sure "Extreme Rows Only" is unchecked and displays "Show All" and then everything will be shown. The table of course can get very long if there are many members.
