Maxon RTD800 Part II (Distortion)

Amazing pedal. This section concentrates on Distortion mode. See part I for Overdrive mode. www.godlyke.com The selectable Overdrive and Distortion modes are configured as follows: The Overdrive circuit features two stages of clipping - a bi-directional clipping diode in the feedback loop of the op-amp and then a single-diode in the second stage for asymmetrical clipping. The Distortion circuit also features two clipping stages, but configured differently - a bi-directional clipping diode in feedback of op-amp for stage 1, and then a 2nd stage with a passive bi-directional clipping circuit. Unlike other tube overdrive pedals, the RTD800 places the tube AFTER the OD/Distortion circuits, making it the best tube overdrive pedal to recreate an authentic tube-amp tone. Gain and Master Controls allow the user to dial the amount of distortion and output level. The three Tone controls are completely independent with no frequency overlap, allowing for an unprecedented degree of tonal options. Everything is kept clean and tight via the variable VCA Noise Reduction circuit, which features an LED status indicator and On/Off switch. In addition, the RTD800 features a Footswitchable Boost function that can be varied between 3-9 dB via an internal trim pot. The RTD800's Front-Panel Controls are as follows - GAIN - Controls Gain level. MASTER - Controls output level allowing user to match effect and bypass levels BASS - Controls low frequency range. MID - Controls middle frequency range. TREBLE - Controls high frequency range. OD/DIST - Switches between Overdrive and Distortion modes. NR - Controls amount of Noise Reduction when NR is switched on. NR ON/OFF - Turns Noise Reduction on/off. BOOST ON/OFF - Engages Boost function. Like all Maxon products, the RTD800 features True Mechanical Bypass switching using a 3PDT switch. The RTD800 comes complete with the Maxon AC2009 9-Volt power supply, an auto sensing digital power supply that can be used anywhere in the world. When you require an unparalleled variety of REAL-tube tones, only the Maxon RTD800 will do.
