Measuring AC current using ACS712 Current sensor | Liono Maker

hi, this is Liono Maker. AC Voltage is in form of sinusoidal shape it depends how you deals with that and calculate it. In this video I performed a practical to measure AC current. I have used ACS712 20A, a current sensor( also called hall effect sensor). It is used to measure both ac and dc current. For measuring Dc Current, we have to make sure I/p Ve+ & Ve- terminals connected at right place. I used Arduino UNO and programmed it to calculate exact current consuming. In my calculations a little bit error is occurring to match the exact current consumed. If you pick it positively it will give you a way to calculate AC current. schematics and Arduino sketch: https://drive.google.com/drive/folder... /////********************************* FOLLOW me at: Facebook page; https://www.facebook.com/LionoMaker/?... ////********************************** Instrucable Page: https://www.instructables.com/member/... ////////////////////////////////////////////////////////////////// Note: "Electricity is dangerous, please use safety tools when you are dealing with high Voltages". ////////////////////////////////////////////////////////////////// Thanks for Like and Subscribe. keep watching. #ACS712calculation #acs712 #CurrentSensor #acs712currentsensor #calculatingACcurrent
