What is Analog Scaling? MicroWIN SMART PLC Practical Guide & Programming | Hindi

Master Analog Scaling in MicroWIN SMART PLC! In this practical guide, we break down how to convert raw analog signals (4-20mA/0-10V) into engineering units using Ladder Logic. Detailed Summary: Whether you are working with pressure sensors, temperature transmitters, or flow meters, scaling is a vital skill for any PLC programmer. This tutorial focuses on the Siemens S7-200 SMART series and the MicroWIN SMART software. In this video, we cover: The Concept behind Analog Scaling. Liner scaling Formula & Excel Sheet explanation. Writing the Ladder Logic using the math instruction instructions in MicroWIN SMART software. Tips & Trick for analog scaling. Timestamps 0:00 Introduction to Analog Scaling in MicroWIN SMART 1:15 Hardware Configuration for S7-200 SMART PLC 3:30 Understanding Raw Values and Engineering Units 5:45 The Linear Scaling Formula Explained 8:10 Step-by-Step Practical Ladder Logic Programming 11:20 Simulating and Testing Analog Inputs 13:45 Troubleshooting Common Scaling Errors 15:00 Conclusion and Further Automation Tutorials 👤 Connect With Me Whatsapp: +91-7389942094 Email: kapil.29jha@gmail.com -------------------------------------------------------------------------------------------------------------------------------------- 🔎 Hashtags #PLC #SCADA #HMI #IndustrialAutomation #Engineering #AutomationEngineer #PLCProgramming #Modbus #Profibus
