RJF 544 Assembly vidéo

In this video, you will learn how to assemble the RJF 544 by following a step-by-step guide. With this video, you will be able to easily follow the detailed instructions to assemble your own RJF 544. The Amphenol Socapex RJF 544 is a rugged RJ45 connection system designed for harsh industrial environments. It is compliant with IEC 60603-7 variante 12 and offers shock, vibration, and traction resistance. The system is sealed against fluids and dust, with an IP68 rating. It is suitable for a wide range of applications, including wireless base stations, video control, robotics, industrial process control, and special machines. The RJF 544 features a quick push-pull coupling system and can withstand a retention force of 100N in the axis. It has improved EMI protection and is compatible with cable diameters from 6mm to 13mm. The system can transmit data at 10 BaseT, 100 BaseTX, and 1000 BaseT networks, and is compatible with Cat 5e and Cat 6 standards. With the patented RJStop system, a standard RJ45 cordset can be used in a metallic plug, which protects it from shock, dust, and fluids. This eliminates the need for on-field cabling and grounding, making installation and maintenance easier and safer. The RJF 544 also offers environmental protection, including resistance to salt spray, vibrations, and extreme temperatures. It is fire-retardant and low-smoke, meeting UL94 V0 and NFF 16102, DIN 5510-2 standards. If you have any questions, please contact our technical support team at Technicalsupport@amphenol-socapex.fr. For more information, please visit www.amphenol-socapex.com.#connectors #assemblyinstructions #instructions #connectorsassembly #cableassemblyandconnectors #connectorassembly #assemblies #D38999 Who we are ? Amphenol Socapex prescribes, designs and manufactures rugged, reliable and innovative interconnection solutions for military & aerospace applications. The company is specialized in standard and customized electrical and fiber optic connectors, contacts, accessories and cabling solutions for harsh environments. LinkedIn :   / amphenol-socapex   Facebook :   / amphenolsocapex   Instagram : https://www.instagram.com/amphenolsoc... www.amphenol-socapex.com
