RD6006-RD6006-W LED Switching Power Supply S-400W (60V-6,6A) from Banggood.com

Model: S-400-xx Output power: 400W Output voltage: DC12/24/36/48/60V (Optional) Input voltage: 110V/220V AC Ambient temperature: -10 ° C ~ +50 ° C Adjustable voltage: ±10% Product size: 215 x 115 x 50mm Item Technical Specifications Output DC voltage 60V Rated current 6.6A Rated power 396W Ripple and noise ① less than 240mV Voltage accuracy ±1% Output voltage adjustment range ±10% Load Regulation less as ±0.5% Linear adjustment rate less than ±1% Input Voltage range 90-132VAC/180-264VAC 47Hz~63Hz; 254VDC~370VDC Efficiency (typical) ② more than 86% Working current less as 5.2A 115VAC, less as 2.8A 230VAC Electric shock 110VAC: 25A, 220VAC: 50A Start, rise, hold time 200ms, 50ms, 20ms: 230VAC Protection Overload protection 105%-135% type: constant current output, +V0 falls to undervoltage point to cut off output, reset: power on again Overvoltage protection , Undervoltage protection , Short circuit protection ,Over temperature protection Environment Working temperature, humidity -10°C ~+50°C, 20% ~90%RH Storage temperature, humidity -20°C ~+85°C, 10%~95%RH Safety Withstand voltage Input-Output: 1.5KVAC Input - Enclosure: 1.5KVAC Output - Enclosure: 0.5KVAC for 1 minute Leakage current Input-output less than 6mA at 1.5KVAC Leakage current Input-output less than 1.5mA at 220VAC Isolation resistance Input-output, input-housing, output-housing: 500VDC/100MΩ Other Size 215*115*50mm Net reset / gross reset 874.1/936.3g ①Ripple and noise measurement method: Use a 12mm twisted pair cable, and the terminal should be connected with 0.1uF and 47uF capacitors in parallel and measure at 20MHz bandwidth. ②Efficiency is tested at an input voltage of 230VAC, rated load, and ambient temperature of 25°C. Accuracy: Includes setting error, linear adjustment rate and load adjustment rate. Linear Rate Test Method: Test from low voltage to high voltage at rated load. Load regulation test method: from 0% to 100% of rated load. The startup time is measured in the cold start state. The fast and frequent switching machine may increase the startup time. When the operating altitude is higher than 2000M, the operating environment temperature should be reduced by 5°C/1000M. Package includes: 1 x Power Supply Buy here : https://www.banggood.com/custlink/3mD... https://www.banggood.com/custlink/vKm... RIDEN® RD6006/RD6006-W Digital Control Switch Adjustable Power Supply DC Module Buy here : https://www.banggood.com/RIDEN-RD6006... Banggood new user gift package: https://banggood.onelink.me/zMT7/mla2... #RD6006-RD6006-W LED Switching #PowerSupply #S400W
