Setup the Modbus TCP communication between a Festo CMMT drive and a Rockwell Micro 850 PLC

This video will help you setup the Modbus TCP communication between a Festo CMMT drive and a Rockwell Micro 850 PLC. To access the relevant files, simply head to the Festo website and navigate to the "Expert Knowledge" section. There, you can find the files you need by using the search term "CMMT Modbus." https://www.festo.com/us/en/search/?t... 0:25 Hardware description 1:57 Software description 2:35 Setup in Festo Automation Suite 3:35 Setup in Rockwell Connected Components Workbench (CCW) 5:25 Importing the Function Block into the project 7:17 Adding Modbus TCP READ block to the program 10:13 Configuring Global Variables for READ 16:05 Copying data from CMMT drive 17:63 Adding the CMMT Function Block 19:31 Adding Modbus TCP WRITE block to the program 20:10 Copying data to CMMT drive 22:43 Configuring Global Variables for WRITE 25:45 Mapping the I/O for the CMMT Function Block 31:55 Getting online with the PLC 37:05 Testing the CMMT Function Block
