13 ADC, fundamentals, operation, how to program the registers, circuits and coding examples

Microcontroller register level programming for the ATmega2560 This nutshell explains the Analogue to Digital Convertor (ADC). Analogue and digital signals are discussed, ADC resolution, voltage resolution quantization errors and reference voltages are explained, The ATmega2560 ADC features and circuit examples are shown. The internal register architecture is described with the five registers, ADCH, ADCL, ADCSRA, ADCSRB and ADMUX showing how they are interconnected, there functions and how to program them. The steps in programming the ADC and examples of single channel and multichannel conversions are shown. Keywords AVR, ATmega, ATmega2560, Atmel, Microchip, microcontroller programming, microcontroller register level programming. analogue to digital convertor, ADC resolution, voltage resolution, quantization error, ADCH, ADCL, ADCSRA, ADCSRA, ADMUX Chapters 00:00 Introduction, analogue vs digital signals 02:36 Resolution, voltage resolution quantization error 04:18 Calculating the input voltage from the ADC conversion. 06:32 Circuits 06:44 ATmega2560 features 08:05 ADC internal circuitry 09:15 ADC registers 14:37 ADC programming steps 15:47 Single channel conversion 19:18 Multi channel conversion
