How to measure resistance using Arduino UNO | Fritzing | Liono Maker

hi, this is Liono Maker. In this tutorial we will learn about how to measure unknown resistance by using Arduino uno. there is simple and fine method to to calculate the unknown resistor. I have been used two resistors, one of them is 1000(ohm) and second is unknown resistor. The second resistor is measured by using voltage divider rule. Resistance: Resistance is a measure of the opposition to current flow in an electrical circuit. Resistance is measured in ohms, symbolized by the Greek letter omega (Ω). Ohms are named after Georg Simon Ohm (1784-1854), a German physicist who studied the relationship between voltage, current and resistance. Voltage divider rule: The voltage divider rule is used to solve circuits to simplify the solution. Applying this rule can also solve simple circuits thoroughly The main concept of this voltage divider rule is “ The voltage is divided between two resistors which are connected in series in direct proportion to their resistance. Components Required: Arduino-uno bread board resistances (1000, 220) connecting wire Software Required: Arduino IDE Fritzing Code and Schematics: https://www.instructables.com/id/Ardu... facebook page:   / lionomaker   //********************************************************************** Thanks For Watching for more interesting videos Like and Subscribe my channel ********************************************************************// #Arduino #Fritzing #ArduinoResistanceMeasurement
