Bowers - XT Analogue Bore Gauges

Bowers XT Analogue Bore Gauges are an economical solution to accurate shop-floor bore measurement. The extended mechanical travel of these advanced two or three point gauges ensures that exchanging measuring anvils is now unnecessary. Their wide application range, 2-300mm, rugged construction and easy read scale, ensure both accuracy and ease of use. XT measuring heads and setting rings are supplied with UKAS certification. Features Range 2-300mm (0.080''-12'') 2-6mm 2 point / 6-300mm 3 point measurement Graduation XTA Micro 2-6mm: 0.001mm, 6-20mm: 0.002mm Graduation XTA Micro 0.080”-1/4”: 0.0001”, 1/4”-3/4”: 0.0001” Graduation XTA 20-300mm: 0.005mm Tungsten carbide measuring faces on all 3-point heads from 12.5mm Blind bore measurement from 2mm-6mm and above 12.5mm (0.500'') Extensions available above 6mm for deep hole measurement Ratchet stop to ensure consistent measurement Setting rings included with individual instruments and sets UKAS certificates supplied as standard with all setting rings UKAS certificate supplied as standard with all XT mechanical gauges Serial number on all gauges Bore gauges manufactured according to DIN 863, part 4 Supplied in fitted case Setting rings included with individual instruments and sets UKAS certificates supplied as standard with all setting rings and gauges Serial number on all digital readouts and measuring heads Heads with special anvils available to suit specific customer requirements (e.g. Threads, grooves, 2-point, spherical, splines etc) Bore gauges manufactured according to DIN 863, part 4 Supplied in fitted wooden case Available in Metric or Inch Available in Individual instrument or in complete set.
