Multi-Chassis Link Aggregation (MLAG) Configuration - COMMANDO C3500 Series L3+ Routing Switches

COMMANDO Marshall C3500 Series Next Generation Core and Data Center L3+ Managed Routing Switches are designed to meet the challenges of next generation Enterprise, Data Center, Metro and HCI (Hyper-Converged Infrastructure). It supports variety of features including MPLS, VXLAN, MPLS SR, and OAM/APS. It offers enhanced wire speed capabilities and higher levels of integration to meet the requirement for edge multi-service access scenarios and the converged network. SOFTWARE HIGHLIGHTS____ Data Center Features • VSF (Virtual Switch Framework) • Priority Flow Control (PFC), Explicit Congestion Notification (ECN) and Data Center TCP • MLAG (Multi-Chassis Link Aggregation) • Overlay technology NVGRE/VXLAN/GENEVE • RPC-API for SDN (Software Defined Network L3 Features • Dynamic Routing (IPv4 Based) BGP4, RIPv1/v2, OSPFv2, IS-IS. • Dynamic Routing (IPv6 Based) RIPng, OSPFv3, BGP4+ • OSPF multiple process • Policy-based Routing (PBR) for IPv4 and IPv6 • VRRP • URPF • ECMP • BFD • IGMP v1/v2/v3, IGMP Proxy • Static Multicast Route • Multicast Receive Control • Illegal Multicast Source Detect • ARP Guard, Local ARP proxy, Proxy ARP, ARP Binding, Gratuitous ARP, ARP Limit • Anti ARP/NDP Cheat, Anti ARP/NDP Scan. Dynamic ARP Inspection (DAI) • DNS Client, DNS Relay • GRE Tunnel • Static Route IPv6 Features • 6to4 Tunnel, Configured Tunnel, ISATAP Tunnel, GRE Tunnel • ICMPv6, ND, DNSv6 • IPv6 LPM Routing, IPv6 Policy-based Routing (PBR) • IPv6 VRRPv3, IPv6 URPF, IPv6 RA • RIPng, OSPFv3, BGP4+ • MLD Snooping, IPv6 Multicast VLAN • MLDv1/v2, IPv6 ACL, IPv6 QoS QoS • 12 Queues • SWRR, SP, WRR, DWRR, SDWRR • Traffic Classification Based on 802.1p COS, ToS, DiffServ DSCP, ACL, port number • Traffic Policing • PRI Mark/Remark ACL • IP ACL, MAC ACL, IP-MAC ACL • Standard and Expanded ACL Based on source/destination IP or MAC, IP Protocol • TCP/UDP port, DSCP, ToS, IP Precedence), VLAN, Tag/Untag, CoS • REDIRECT and Accounting based ACL • Rules can be configured to port, VLAN, VLAN routing interfaces • Time Ranged ACL Security • 802.1x AAA • Port, MAC based authentication • Accounting based on time length and traffic • Guest VLAN and auto VLAN • RADIUS for IPv4 and IPv6 • TACACS+ for IPv4 and IPv6 • MAB DHCPv4/v6 Traffic Monitor • DHCP Server/Client for IPv4/IPv6 • DHCP Relay/Option 82, 252 • DHCP Snooping/Option 82 Link Aggregation • 802.3ad – Link Aggregation Control Protocol (LACP) • Multi-chassis Link Aggregation (M-LAG) MPLS • LDP • RSVP • LDP tunneling (LDP over RSVP) • Fast reroute (FRR) • IPv6 tunneling (6PE) • Ingress, transit, and egress label-switched paths (LSPs) • IPv4 Layer 3 VPNs • IPv6 Layer 3 VPNs (6VPE) • Layer 2 circuits Visibility • Switched Port Analyzer (SPAN) • RSPAN • ERSPAN • Port mirroring • sFlow Data Center Bridging • Priority-based flow control (PFC)—IEEE 802.1Qbb • Data Center Bridging Exchange Protocol (DCBX), DCBx FCoE, and iSCSI type, length, and value (TLVs) Data Sheet: https://www.commandonetworks.com/swit... Configuration Guide: https://www.commandonetworks.com/swit... CLI Guide: https://www.commandonetworks.com/swit... Gallery: https://www.commandonetworks.com/gallery
