progeCAD AEC Architectural Tool - Features Overview

A quick introduction to the new progeCAD AEC Architectural Tool: Compatible with AutoCAD®AEC Objects. The new AEC package allows you to draw 3D architectural elements with a two-dimensional view in plan and takes advantage of a whole series of new Architecture style commands. The drawn entities are now specific AEC elements editable and configurable via the Styles management. Main Features: Draw walls, doors, curtain walls, windows, stairs and railings Draw slabs, roofs, or roof slabs Walls and Slabs can be created by direct conversion of 2D entities Multi-level manager to assign levels to AEC entities AEC Styles manager: manage & customize AEC Styles for Walls, Doors, Windows, Curtain Walls and Curtain Wall Units, stairs and railings, and slabs AEC Family – imports AEC objects style from external fam or dwg files
