Perini complete Tissue Converting Line with lamination (Wotol ref 2274184-2-CP)

Type : Complete 2710 mm 170m/ min Rewinder with Perini lamination type 49.01 , 1 unwind & packaging, still working Year(s) : 1987, 1990, 1992 Equipment all refurbished 2017, Wrapmatic packaging unit of 1990 ( able to pack: TP & KT) & Cassoli SRT roll bundler 1992 This TP & KT complete line includes: 1/ Unwinder Fabio Perini Max paper width 2710 mm Working speed up to 300 m/min Max roll diameter 1300 mm Number of unwinder stand belts: 1 Max roll weight: 1300 Kg Lubrication system : yes Roll fixing: pneumatic Roll ending detection: yes 2/ Lamination and Embossing Unit Fabio Perini 49.01 Refurbished 2017 Max width: 2710 mm Max paper width: lamination roll 2710 mm Working speed: up to 450 m/min Steel roll lubrication system yes Embossing model DEZ Number of paper plies: 4 Dancer roll: yes 3/Rewinder Fabio Perini Refurbished 2017 Max paper width 2710 mm Working speed up to 300 m/min Max logs/min 10 Log Diameter min/max 90/150 mm Core diameter 46 mm Paper grammage 15 – 60 gr / sqm Nr of perforation blades 4 Perforation length: manually adjusted minimum 105 mm to maximum 420 mm. Pick up with glue Web tension control: Through dancer roll Glue feeding: Pneumatic pomp Log diameter control: Electronic Sheet count: Electronic until the diameter obtained Core lift: Yes Core transfer on conveyor: Yes Automatic paper feed: No Paper brake detection by photocells: yes 4/ Tail Sealer Fabio Perini Length of the log end: Adjustable Pressurized glue tank: Yes Log reject conveyor: Yes 5/ Log accumulator Fabio Perini Max log length 2710 mm Capacity (log diameter 90/150 mm standard) 164 6/ Log saw Fabio Perini with Trimex Refurbished 2017 7/ Core maker Fabio Perini PC210 1983 Core length: 2710 mm (adjustable) Carton weight: 135 – 220 g/m2 carton width : 70 mm ; 80 mm Nr. plies: 2 & 3 Core diameter: Ø = 46 mm 8/ Consumer Packaging WRAPMATIC MULTIWRAP 30/A ––of year 1990 Max speed 60 packs/min ( depending on the format ) Min roll diameter = 90 mm Max roll diameter = 140 mm Packing material LDPE TP- 4 rolls up to 48 KT – 2 rolls up to 16 9) Roll bundler CASSOLI SRL IN/5 SUPER HCO Min roll diameter = 90 mm Max roll diameter = 140 mm Packing material LDPE
