3D Printed Gearbox Planetary for RC Motor

This is one of the SMALLEST FDM 3d printed Planetary Gearboxes / Drives. The dimension of the case gearbox is only 26x26mm! SUBSCRIBE! https://www.youtube.com/jtronicsTV?su... so you don't miss our new videos jtronicsTV. You could find the files under https://cults3d.com/en/users/jtronics . This is a gearbox for various motors. I designed the gearbox to test how durable 3D printed gears are. So the test is a part of a bigger project that I am working on. Maybe someone will find this project usefull. It's Easy to print and assemble and the gearbox runs really good. The gearbox has a reduction of about 1:4.7. This gives you a higher torque . You coud use it with DC or Brushless motors with a mount diagonal of 16mm, 17mm or 19mm or you could add other holes. . I used the following materials http://www.jtronics.de/go/pla-silberm... http://www.jtronics.de/go/pla-hellblau http://www.jtronics.de/go/pla-gelb . additional parts: 1x Motor 2x M3 or M2 countersunk screws for motor 4x M2x10mm screws for case 3x M2x6 screws to fix the planet gears 1x 3mm axis or M3x10mm screw 3x bearing MR52zz 2x5x2.5mm 1x bearing MR83zz 3x6x2.5mm . Visit our channel for more interesting videos    / jtronicstv   . ———————————————————————————————— . Website: http://www.jtronics.de/ Instagram:   / jtronics.de   Twitter:   / jtronics2   youtube:    / jtronicstv   Facebook:   / jtronics.de   Thingiverse: https://www.thingiverse.com/jtronics/... Cults3d: https://cults3d.com/en/users/jtronics
