3” Giddings & Lewis Table Type Horizontal Boring Mill, Model 300T, SN FASCT-1109 / A VERY RARE FIND!

MACHINERY CONSULTANTS INC BILL WILSON JR. TECHNICAL SALES MGR. 1390 W. 200 S. Salt Lake City, UT 84104 Ph: 801-531-9500 Fx: 801-531-9555 Em: mci@machineryconsultants.com www.machineryconsultants.com Pre-Owned 3” Giddings & Lewis Table Type Horizontal Boring Mill, Model 300T, SN FASCT-1109 General specifications are approximate and are subject to verification. Diameter of Spindle: 3” Spindle Taper: Morse Taper #5 MT Spindle Travel: 24” to 25” Spindle Speeds: 36 changes, from 22 to 1600 RPM Spindle Feeds: 36 changes, from .003 to .125 IPR Table, Saddle Feeds: 18 changes, from ¼ to 30 IPM Working Table Surface: 36” x 72” Table Cross Travel: 67 ½” Vertical Travel: 48.5” Saddle Travel: 57 ½” Main motor: 10 HP / USA Electrics - Very Clean Electricals: 220/440 Volt ( at 220 Volts Now ) Approx. Weight: 25,000 Lbs. Approx. Dimensions: 14’ Length x 9’ 4” ( 112” ) wide X 118”H Height for shipping: ( for a 5” blocks allow 123” Tall) + 5” Complete with: • Built in Outer Saddle Supports (Outriggers) * *Very Compact Frame Design HBM • Power Rapid traverse in All Directions • Pendant Control *** Note all USA Made electricals in V Nice condition 10 HP / USA Electrics - Very Clean & Sanitary Set up • Set up to accept Facing Head w/the Facing Head Clamp Plate • Set up to accept Tailstock, it currently has the Tailstock Drive Shaft • Tailstock Unit available: • Facing Head w/the Facing Head Clamp Plate is available: • 22” Diameter G & L Facing Head w/the Facing Head Clamp Plate is available: Condition: machine is in very good condition, it recently came in from a Light duty R & D Research shop, very well tooled w/OEM G & L Items, as needed, Original Flaking highly visible, Sounds Excellent Inventory No: 22-1120
