EMCS_SMS + AP-I-4IOL + IO-Link + CPX-AP-I-PN + CPU1200 v17 + ProfiNet + Backup & Restore

This video describes how to configure and use the Backup/Restore feature with Festo CPX-AP-I-4IOL IO-Link master and a SMS (Simplified Motion Series) device Connected to CPX-AP-I-PN and Siemens S7-1200 CPU. There are some files (within a “zip” file) to accompany this video that can be retrieved at the following Google drive link: https://drive.google.com/file/d/1QdzT... (0:00) Overview (2:30) TIA Portal Device setup (2:52) TIA Portal Hardware Detection to find the CPX-AP-I-PN (3:36) TIA Portal Hardware Detection does NOT find the CPX-AP-I-4IOL – Configure CPX-AP-I-4IOL manually (6:09) TIA Portal Compile and Download program (6:54) Festo website download Siemens application guide with FB's (Function Blocks) for CPX-AP-I-PN (7:22) Festo website download Festo IO-Link Tool software for CPX-AP-I-4IOL (7:50) Festo IO-Link Tool software – Add Master CPX-AP-I-PN (10:32) Example device replacement WITHOUT Backup/Restore activated (15:00) TIA Portal activate Backup/Restore (17:10) TIA Portal Compile and Download program (18:00) Example device replacement WITH Backup/Restore activated – modify parameter with Festo IO-Link Tool software (21:50) Festo website download Siemens Application guide with CPX-AP_Festo_Lib v1.3 with FB's (Function Blocks) for CPX-AP-I-PN/ CPX-AP-I-4IOL (22:40) explain function/configuration/use of the library CPX-AP_Festo_Lib v1.3 (37:00) TIA Portal Compile and Download program (37:45) CPXAP_Parameter FB (Function Block) testing (38:38) CPXAP_IOLink_Parameter FB (Function Block) testing with EMCS/SMS Parameter 256_0 Speed (39:05) Example device replacement WITH Backup/Restore activated – modify parameter with PLC WITHOUT System Command (44:10) Example device replacement WITH Backup/Restore activated – modify parameter with PLC WITH System Command (46:20) CPX-AP-I-4IOL (Backup/Restore activate) default device name of EGSS-BS-KF-32
