CANchecked Support Call 1 - Basic DSS operations and widgets

Our very first support call via Zoom with some people in the chat asked questions If there are additional topics, you'd like us to cover, drop us a comment. some important links: www.canchecked.de/help find all downloads to your product 00:00 intro 00:27 initial connection (ignition turned off for initial connect) 02:04 TRI editor - sensor rename, decimal places, minimum/maximum values (graphic scaling) 03:59 Pages - demo mode, graphical scaling (round widget), change widget sensors/colors 07:50 overlay widget - basic warnings 09:23 round widget - start/end angles, sensor name 10:23 add a text field 11:55 sensor value - widget warnings min/max 12:56 the widget list - identify, hide, sort widgets 14:44 change widget sensors 15:45 keyboard shortcuts (arrows to move, delete/copy/paste widgets) 16:22 the help button 17:15 round meter - change colors 17:47 needle widget (ghost) 18:20 change logo picture in page 20:05 upload the picture a second time - erase flash 21:30 "picture missing" error (yellow bar in display) 22:44 add "predefined page" (incl RPM bar widget) 25:36 own custom page (incl RPM bar) 33:12 add "icon widget" 36:44 "gear widget" 39:00 setup gear ratios on the display itself for gear calculation 40:27 "grid lock" - position your widgets in a grid 41:38 upload own pictures 42:49 change to imperial units / use of the multiplier 46:26 add and calibrate analogue inputs (NTC temperature, oil/fuel pressure) 54:05 "performance meter" widget 54:40 load "predefined page" - 6 cylinder 56:40 upload a TRI file from DSS into display from internal storage 57:42 change pages on the display itself with touchscreen 59:58 hide pages in DSS 01:01:54 activate/change splash screen (incl "erase flash") 01:05:08 define start page 01:05:42 hide pages on the display with touchscreen 01:06:55 solve DSS not loading page / stuck on one page
