Pimp My Snapmaker Original - Mod No. 1: "Modify CNC 2.0 Module for using with Snapmaker 1.0"

Pimp My Snapmaker Original I love my little Snapmaker Original (1.0), I bought at Maker Fair Berlin 2019 for just 500 Euro. But if you are a maker, you want to make things better. So I startet to pimp my Snappy. I will share all my modifications here and on instructables.com. Mod No. 1 - CNC 2.0 Module for Snapmaker Original The Snappy is really a very valuable high quality machine. But the CNC Module for the first Version is absolutely "&%$§$§!" (Trash!) - Sorry dear Snapmaker Guys! no precision no force if the spindle got stuck, the thin 3.14 mm shaft get bent maximum 3.14 mm diameter tools The CNC 2.0 Modul is more precise, uses an ER11 clamp ant tool up to 6mm diameter. So I bought a CNC Module for the Snapmaker 2.0. After exploring the connection of the CNC 1.0 module, I developed a pcb with a RJ45 socket for connection to the Snapmaker Original controller in fitting in the housing of CNC 2.0 Module. It works really fine!!! If you are interested, feel free do my modification for you Snapmaker. Please notice, that some modifications void the manufacture guarantee. You do all modifications on your own risk! Parts you need: Snapmaker Original of course CNC Module for the Snapmaker 2.0 RJ45 socket for horizontal PCB mount prototype PCB or the custom PCB I designed (watch https://aisler.net/p/XQKESJTJ) 1x Resistor 100 Ohm 1x Resistor 4.7 K 1x Mini DC Step-Down Module - 24 V DC to 3.3 V DC 4 pin pcb header 2x M3 embedded nuts 3D printed mounting parts, I designed with Autodesk Fusion 360 the 2 jst connectors, I desoldered from the CNC 2.0 board Tools you need: soldering station (desoldering station) 3D Printer (your Snappy;-) How to: Check out on: https://www.instructables.com/Pimp-My... Just watch the photos and this YouTube Video. Coming soon: Mod No. 2 - Change Position of Filament Holder Mod No. 3 - Add Light Stripe Mod No. 4 - Add Auto Power Off Mod No. 5 - Change Position of Touchscreen Mod No. 6 - DIY Controller with Joystick Mod No. 7 - I don't know. We will see. ;-) https://www.instructables.com/member/...    / seppomane     / austelmusic
