Installation and Startup for the Quest-tec Magne-Trac Magnetic Level Gauge

The Quest-tec Solutions Magne-Trac utilizes a non-magnetic pipe chamber mounted directly to a vessel. The process connections from the chamber to the vessel act as an inlet and outlet that allow the liquid level in the pipe chamber to match the level in the process vessel. Inside the chamber, a custom designed float rises and falls with the level of the liquid in the chamber. A 360º magnet array within the float projects a magnetic field through the pipe chamber to an externally mounted indicator to provide a visual read out of the liquid level within the vessel. The Magne-Trac™ level indicator is easy to install, low maintenance, and easy to view. Accessories include point level switches and transmitters to provide integration into plant control systems. The Quest-tec Solutions Magne-Trac Plus combines the Magne-Trac magnetic level gage with the Bridle-Trac by pass chamber. It may be used with our VAR Partner E&H GWR or customer specified radar for redundant level measurement. The Magne-Trac Plus is recommended in applications that require both visual and electronic level viewing. For more information on Quest-tec products, contact Automatic Controls of Virginia. Call us at (804) 752-1000 or visit our website at https://acva.com.
