Rebuilding a CNC's Brain: 1000 Wires to 1 Perfect Board

I rebuilt my CNC’s entire wiring system and replaced more than 100 messy cables with a single clean, reliable circuit board. This upgrade didn’t just tidy things — it completely changed how the machine works. This is Part 2 of my CNC retrofit project, where I rebuild a 1992 machine with modern electronics, proper power distribution, and clean engineering principles. If you like satisfying before/after transformations, this one is great to watch even if you’ve never wired a CNC before. You’ll see how I: • designed a custom breakout board in EasyEDA • cleaned up a wiring mess that grew over 30 years • integrated sensors, probes (including a Renishaw-style 5V probe), VFD control & drivers • added power protection and clean routing for future upgrades (ATC, Delta B3 servos) • made the Centroid Hickory controller the core of a reliable system Whether you’re retrofitting a machine or just enjoy engineering makeovers, this is a fun deep dive into solving real electrical problems with a clean PCB solution. ✅ CHAPTERS: 0:00 - Why the Wiring Had to Go 0:27 - Board Design in EasyEDA 0:45 - Inputs: Sensors & Probes 1:05 - Outputs & Drivers 2:26 - Power & Protection 2:57 - Special Interfaces (Renishaw, VFD) 4:00 - ATC Driving Solution 5:00 - PCB Unboxing 6:00 - Stencil & Solder Paste 6:18 - Hand Placing SMDs 7:40 - Reflow Process 8:12 - Final Assembly 8:42 - Finished Breakout Board 🔔𝐃𝐨𝐧'𝐭 𝐟𝐨𝐫𝐠𝐞𝐭 𝐭𝐨 𝐬𝐮𝐛𝐬𝐜𝐫𝐢𝐛𝐞 𝐭𝐨 𝐦𝐲 𝐜𝐡𝐚𝐧𝐧𝐞𝐥 𝐟𝐨𝐫 𝐦𝐨𝐫𝐞 𝐮𝐩𝐝𝐚𝐭𝐞𝐬.    / @theyieldpoint   🔗 Stay Connected With Me. Discord:   / discord   Website: http://cncrouterinfo.com/ 📩 For business inquiries: cncrouterinfocom@gmail.com ============================= 🎬Suggested videos for you: ▶️    • Everyone Told Me This CNC Was Junk — They ...   ▶️    • Custom 3D Printed Tool Holders Turn IKEA P...   ▶️    • I Converted a Silent Compressor to 3-Phase...   ▶️    • My New 2,000lb Beast: The Workshop Will Ne...   ▶️    • Servo Tuning in 30 Seconds?   ================================= #CNCWiring #CNCUpgrade #DIYCNC #CircuitBoard #PCB #CNCProjects #CNCretrofit How To Fix CNC Wiring Problems With A Custom PCB | Easy DIY Retrofit Upgrade
