four sides seal with coffee valve pouch bag machine---KUNRUN GROUP

four sides seal with coffee valve pouch bag machine---KUNRUN GROUP SKB600-ZMTV High Speed Center-sealing Bag Making Machine SPC（Contract agreement 1) 1.Function: Center-seal bag， Center-seal with side gusset bag Four sides seal bag， Four sides seal with one-way coffee valve bag. Center-seal with middle tape bag, double cutter feature(including round corner punches) Coffee valve applicator machine( need skip feed feature). Frame unit color is black Bottom K punch( 75 depth) chiller machine(1.5P) Hand punch bottom K-sealing plant. QUT. Punch unit. 15 inch touch screen 2.Material:BOPP，CPP，PET，PE，Nylon and Aluminum and other plastic laminating films and paper-plastic laminating material. 3.CONFIGURATION: 1).Material Max.size:1200*Ø800mm(Ø76mm paper core). 2)Bag making high speed:20-180shots/min (By bag length, the original film material, such as setting the length of four blank bag speed). 3)Unwind line speed:36m/min. 4)Sample bag size:Min. to Max. as following: L=80 to 400mm,L1=100 to 600mm,L2=20 to 70mm. 5)Driving mode:3.7KW Inverter drive & motor. 6)Main Traction servo motor: Three servo motor. First group traction:1.5KW 1set. Second group traction:1.0KW 1set. Third group traction:1.5KW 1set. 7)Control system: PLC control system, touch screen and standard tension control. 8)Front folding device: 3sets, first center folding board, middle center folding board and back side gusset folding board. 9)Back folding device: 1set, depend on four guidance board to set up different size for side gusset and bag’s width. 10)Coffee valve unwind machine: 2sets, automatic control unwind, insert and sealed. 11)Middle tape unwind unit: 1set, automatic tension control by machinery. 12)Temp.: 13 sets, PC temp.control. 13)Power source: 3 phase, 220V±10%,60HZ. 14)Unwind motor:0.4KW. 15)Unwind motor inverter: 0.75KW 1set. 16)EPC:1 sets. 17)Total power consumption:35KW. 18)Wall board thickness:14mm. 19)Nickel-plated surface parts (corrosion preventive) treatment,Shell with drawing stainless steel. 20)Machine overall size:14000mm*1750mm*2400mm. 21)Machine weight:7800kg. 22)Table devices: single-phase capacitor motor with gear drive belt, for bulk delivery time. 23)Unwind tension: Handle.Tension sensor: Auto constant tension. 24)K-sealing unit: 1set and installation on cross heater. 25)Hand punch: 1set. 26)Detection function for connect: 1set and installation at back of vertical heater. 4.Sealing hot press and cool press unit 1)Horizontal sealing:4 groups,length:640mm,power consumption: 2.5KW. Horizontal cooling :1 groups,Length:640mm. NOTICE: SEALING AND COOLING UNIT NEED SKIP FEED FEATURE! 2)Vertical heat sealing:1 group, length:800mm,power consumption:2.5KW. Vertical cooling :1 group,Length: 450mm. 3)Vertical heat sealing unit for four side seal: 2 groups, length:620mm. Vertical cooling unit for four side seal: 2 groups, length:340mm. 5. Special servo motor: Double cutter servo motor:1KW 1set Whole cutter device servo motor:0.4KW 1set 6.Equipment Supply Requires
