How is a miniature relay made?

Miniature relays https://www.relpol.pl/en/Products/Min... are devices that work in the devices that surround us on a daily basis, e.g. in gastronomy, household appliances, lighting, medical equipment, monitoring, alarm systems. They can therefore be used in electronics https://www.relpol.pl/en/Products/Min..., but also mounted in sockets, e.g. in industrial automation, electrical applications, in applications with PLC controllers as input/output separators https://www.relpol.pl/en/Products/Int... Relpol is the only Polish manufacturer of miniature relays, which started its adventure with relays in 1958. In the film, we present the entire process of creating miniature relays, which consists of 8 very complicated and precise stages. Initially, the individual parts of the relay (body, coil, electromagnet, core) are manufactured, which are connected together in subsequent stages. The most complicated stage is the assembly of all previously manufactured elements into a ready relay. The correctness of assembly on each of the individual sections is checked with video cameras. A 100% electrical measurement of each relay is also carried out on the same device. At a later stage of production, the relays are encapsulated and tinned, so that they can go to the final electrical control and laser printing.
