USED SIP HYDR-8P JIG BORER

USED SIP HYDR-8P JIG BORER Working Surface 61 3/4"x 40 1/2" Working Speeds (18) 40 to 2000 RPM on vert spindle horiz spindle speeds (15) 40 - 1000 rpm Quill Diameter 4.710 Spindle Quill Traverse 12" Spindle Feed 8 Selections 0.001 to 0.0025 F.P.R. Specifications: Table Length 61-1/2" Width 40-1/2" Number of T-slots 10 Hydraulic travel 52" Additional hand travel for fine setting 4" Nominal measuring travel 55" Hydraulic coarse setting speed 9 or 11 feet/min (*) Milling feeds, up to 12"/min Saddle of the vertical spindle Nominal transverse travel 40" Coarse setting speed 5 or 6 feet/min (*) Milling feeds, in/min 1-2-3-6 or 1-1/8 2-1/4 3 3-1/2 Vertical spindle head Tool shanks SIP-50-Taper Quill travel 12" Number of spindle speeds 18 Lowest speed 40 rpm Highest speed 2000 rpm Lowest feed, per revolution of spindle 0.001" Number of quill feeds 8 Spindle rapid traverse 3-1/2 or 4 ft/min (*) Cross Rail Speed of the vertical travel 14 or 17 in/min (*) Free space between uprights 57" Distance from table top to vertical spindle nose 38-1/4" max. Horizontal spindle head Tool shank with SIP-50-Taper Quill travel 12" Number of spindle speeds 15 Lowest speed 40 rpm Highest speed 1000 rpm Number of quill feeds 8 Lowest feed, per revolution of spindle 0.001" Saddle of the horizontal spindle head Distance from table top to spindle center max. 31-1/2" Distance from table top to spindle center min. 3-1/4" Vertical power traverse Coarse setting speed 17 or 21 in/min (*) 3 milling speeds 8-1/2 - 4-1/4 - 2 or 10-1/2 - 5 - 2-1/2 in/min (*) Coolant pump Delivery, per minute 12 pints/min Reservoir capacity 5-1/2 gal. Weights Counterweight of the vertical spindle 420 lbs Counterweight of the horizontal spindle head 1800 lbs Net weight of machine appx. 17 tons Overall size 10' L-R x 14' F-B x 10' 9"H Permissible load Permissible load on the worktable 2 tons RACK FULL OF TOOLING SEE PICTURES
