Velocity® Ascendant® 107’ Heavy-Duty Aerial Ladder - Single-Rear Axle – Leon Valley, TX

Leon Valley Fire Department’s #Velocity 107’ #AscendantLadder features an EMS compartment between the cab doors with additional storage added directly behind the crew cab for long tools. They chose to omit the step on the driver’s side rear for large equipment storage and added two swing-out, fold down steps off the rear for better hose and tool access. The officers’ side pump panel of the #AerialLadder contains a hose tray with retention of the hose for quick connection to hydrants. Angled handrails allow for ease of access when getting in and out of the apparatus. #FDIC2023 #LeonValleyTX CHASSIS Chassis: 70” Velocity cab with 10” raised roof Seating Capacity: 5 Overall Height: 11’ 9” Overall Length: 39’ 6.25” GVW Rating: 57,500 lb Safety: Side Roll and Frontal Impact Protection Front Axle: #TAK4 Independent Front Suspension, 24,000 lb Rear Axle: Meritor RS30-185, 33,500 lb Electrical: Command Zone™ Advanced Electronics System BODY Material: Aluminum Shelving: Adjustable, up to 500 lb Doors: Rollup Pump: Waterous, 2000 gpm Tank: 500-gallon Pump Panel: Pierce® Control Zone™, 52” Foam: #Husky12 Foam Cell: 25-gallons AERIAL DEVICE: Device: Ascendant 107’ Heavy-Duty Ladder Reach: 107’ vertical, 100’ horizontal Tip Load: 750 lb dry, 500 lb wet Equipment: 100 lb allowance Flow Rate: 1500 gpm Stabilizers: 1 set, 18’ spread, 1 down-jack Job Number: 37442 Dealership: Siddons-Martin Emergency Group
