DIY: BMW E39 Rear Door Panel Removal

Video tutorial on how to remove the rear door panel on a BMW E39. The video does cover on the removal of the driver's side door panel, which will be the same for the passenger side as well. Vehicles equipped with sun shades maybe slightly different. Removing the door panel will give you direct access to the inside of the door such as working on the window regulator. This particular tutorial was done on a 1997 BMW 540i sedan. Website: http://4diyers.com Facebook:   / 4diyers   Google Plus: https://plus.google.com/+4DIYers Twitter:   / 4diyers   Instagram:   / 4diyers   Tumblr:   / 4diyers   Pintrest:   / 4diyers   Tools/Supplies Needed: -small standard/flat screwdriver -standard/flat screwdriver -phillips screwdriver -nylon wedge trim tool -tape -socket set Procedure: -remove the window switch panel using a standard screwdriver, wrap the tip in tape so it doesn’t scratch the door or plastic and slowly work it around the edge of the switch panel -once the panel is far enough out, use your hands to remove the rest -depress the tangs on the electrical connector and remove the switch -tuck the wires into the hole once done so the connectors won’t bind up during removal -unscrew the lock cap -unclip the door light on the bottom of the panel from the backside, unplug the electrical connector and feed the wire back into the hole -using a small standard screwdriver wrapped with some tape so it won’t scratch the plastic, remove the plastic cap in the door handle pocket -remove the phillips screw hidden behind that cap -using the nylon trim tool, pop it in between the door panel and door assembly, then slowly work it around and unsnap the clips along the sides and bottom -lift the panel upwards, there will be a snap clip in behind the pull handle which can be slide out of it’s place -feed the plastic handle casing through the hole -the top of the panel just unclips from the top and the chrome trim stays in place on the door -disconnect the speaker wiring -remove the window switch panel wiring from the hole -remove the wire from the light on the bottom of the door panel -the clip from the handle does need to be removed for door panel installation which is done by using needle nose pliers to depress the metal spring clip and remove the plastic portion, then slide it back onto the door panel -reinstallation in reverse of removal Thank you to all those who watch my videos and support my content. Don't forget to subscribe to my channel for future tutorial videos and like my video if you found it helpful. New videos are always being uploaded every week! © 4DIYers 2013 All Rights Reserved No part of this video or any of its contents may be reproduced, copied, modified or adapted, without the prior written consent of the author.
