DIY Class AB Powerful Amplifier With Two 2SA1943 Transistor / super simple

➤ In today's video, build the class ab amplifier using TWO A1943 transistors (PNP) with 4558 IC, very simple and powerful. ➤ DIY Class AB Powerful Amplifier With Two 2SA1943 Transistor / super simple ➤ Copyright © by Share Tech Creative ➤ Follow me:    / sharetechcreative…   ➤ Follow Facebook: https://bit.ly/3eEHjNb ➤ 📺 Thanks for watching! ➤Schematic diagram: ➤ Parts Required: Transistor, ic: – 2SA1943 x 2 – TIP 41C – TIP 42C – 4558 IC Capacitor: – 33p – 0.1uF x 1 – 0.22uF (224) x 2 – 1uF(105) x 2 – 100uF/16v x 1 – 100uF/25v x 2 Resistors: – 10R/5W x 1 – 300R/1W x 2 – 33R x 1 – 470R x 2 – 1K5 x 1 – 2K7 x 2 – 3K3 x 1 – 5K6 x 1 – 15K x 2 – 33K x 2 – 100K x 1 – 50k x 1 potentiometer – Aluminum heatsink – Mica pads x 2 – Diode 4007 x 2 – Diode Zener 15V x 2 – Connector 2-Pole 5mm (connect to speakers) – Connector 3-Pole 5mm (connect to power supply) Power supply: 30V 0V 30V transformer See how to assemble power for the amplifier:    • How to make Dual Power Supply Transformer ...
