FLOOR ,ROOF AND LEVEL UP IN REVIT !! REVIT ARCHITECTURE BEHINNER !! BESUC REVIT #05 #architecture #autocaddesign #sketchup #home #revitmodelling #ptscad In Revit Architecture, understanding how to create and modify floors, roofs, and levels is key to mastering the basics of designing architectural models. Here's an overview to get you started: 1. FLOOR in Revit A floor in Revit represents the horizontal surfaces of your building, such as ground levels, mezzanines, or upper floors. Steps to Create a Floor: Go to the Architecture Tab: On the ribbon, click the Architecture tab, then click the Floor tool. Select a Floor Type: In the Properties palette, choose the type of floor (e.g., concrete slab, wood, etc.). Sketch the Floor: You’ll enter the Sketch Mode, where you can draw the boundary for the floor. Use drawing tools like Line, Rectangle, or Pick Walls to define the edges. Finish the Floor: Once you’ve sketched the boundary, click Finish Edit Mode in the ribbon to generate the floor. Adjust Floor Properties: Modify thickness, material, or structure by selecting the floor and editing its properties. Tips: Ensure the boundary is closed; otherwise, Revit won't allow you to finish the floor. You can edit the floor later by selecting it and clicking Edit Boundary. 2. ROOF in Revit Roofs can be created using a variety of methods, including footprint-based roofs, extrusion-based roofs, and more. Steps to Create a Roof: Go to the Architecture Tab: On the ribbon, click the Architecture tab, then click Roof. Select Roof by Footprint: This is the most common method for creating a roof. You'll sketch the boundary directly on a plan view. Just like floors, use sketch tools to define the roof shape. Choose Roof Type: In the Properties palette, select the type of roof (e.g., gable, flat, etc.). Set Roof Slope: If you want the roof to have a slope, select the edges of the boundary and assign a slope in the options bar. Finish the Roof: Once you’ve defined the shape, click Finish Edit Mode. Tips: You can modify slope by selecting individual roof edges and changing the Defines Slope property. Use Roof by Extrusion for more complex roof shapes, like curved or arched roofs. 3. LEVELS in Revit Levels in Revit define the vertical heights of different floors or components in your building. All elements, such as floors, roofs, and walls, are associated with levels. Steps to Create a Level: Go to an Elevation View: Levels are best viewed and created in an elevation or section view. Go to the Architecture Tab: Click on the Architecture tab, then click Level. Draw the Level: In the elevation view, draw a horizontal line to represent the new level. Use the Pick Line tool if you want to create a level at a specific distance from an existing one. Adjust Level Height: You can modify the height of the level by selecting the level and entering the desired height value. Naming Levels: Levels are automatically named (Level 1, Level 2, etc.), but you can rename them to indicate their function (e.g., Ground Floor, Roof Level). Tips: When you create a new level, you can automatically create corresponding floor plans by checking the Make Plan View option. All objects associated with a level (walls, floors, roofs) will adjust if the level height is changed. Putting it All Together: Floors are based on your Levels. Roofs can reference your Top Level and provide coverage for the building. Modify these elements by selecting them and using the Properties palette to fine-tune their specifications. Helpful Shortcuts: WA: Create walls. FF: Create floors. RO: Create roofs. LL: Create levels. As a beginner, practice creating simple floor plans, adding roofs, and adjusting levels to become comfortable with these essential tools!
