Genie S40 ROTATOR Tator got keep em rotating. DONE and working!!!!!!

Finished with all the major topics on my Genie S40 Boom. The last was rebuilding the basket Rotator. It took a little thought to make sure I got it back together correctly, but all is working just as expected, but without the leaking. There was some crap in the unit around the flat bearings, but didn't require any machining to clean it up. Given this was the unit that came on the lift, needless to say it is obsolete. It is an #Helac #HP-9k-25724 Genie P/N 30669. The repair documentation was scarce but Parker-Hanifin (now owns the Helac product line). Product Engineer turned me on to come. Was very helpful. The replacement unit is a Helac L20 - 8.5. This documentation was also helpful. The one real challenge I had was making sure I had the gear sets timed properly as none of the documentation I had was in accordance with my unit, but got through it fine. The key and glad I did wast to mark the Flange and Body. The flange is a single unit with the shaft & gear. Having done this wound up being super critical.The video is a bit long but there are sections with pretty good info should you have similar unit. Unit swings 180 and 160 just fine. #HP-9-CL-180/160-LF-H, #ModelHP-9-180, #Genie30669, Seal Kit Genie #65842GT, Helac #S25356 Helac Bearing Kit #25403
