1974 Hiwatt DR103 Repair - Part 4

This video covers installation of new filter capacitors as well as a new bias capacitor on a 1974 Hiwatt DR103 amplifier that i bought for $1000 in 2019, including what was previously modded and what will need to be ordered and replaced to bring the amp back to a stock condition. This series will cover the repair and restoration of this amp including topics such as testing an output transformer, replacing the output transformer, filter capacitors, tubes, and returning to the circuit to stock. We will also look into and install a voltage doubler circuit for the bias supply if necessary. Part 4 will cover installation of new parts to bring amp back to stock Part 5 will cover sound tests (Subject to change based on any surprises that pop up along the way) 00:00:00 Intro 00:03:02 Cleaning Solder Residue 00:04:13 Prepping Filter Caps 00:05:46 Taking Some Measurements 00:07:25 1st Cap Installed 00:08:32 Removing Resistors on the Caps 00:09:22 A Couple More Caps Installed 00:10:48 Capacitor Contortionist 00:12:05 All Filter Caps Installed 00:13:24 Bias Cap 00:14:36 Outro Layout for DR103 found here: https://hiwatt.org #amprepair #GuitarAmp #GuitarAmplifier
