How to install Robox Dual Material Kit & Second Extruder + Install/Upgrade (RBX01-DMKIT-SP2)

Timecodes 0:00 - Make sure power is off and all cables are disconnected 0:05 - Open up cover and remove the print head. 0:13 - Turn the printer and expose the left side bottom screw 0:39 - Remove side panel 1:04 - Remove filament guide 1:12 - Remove extruder 3:01 - Remove timing belt 3:21 - Remove clear side panel 4:45 - Remove X carriage rod holder 7:08 - Remove reel hub 9:38 - Install new reel hub 11:08 - Remove X carriage 12:10 - Remove bowden tube holder 12:30 - Install bowden tube holder 13:09 - Install ribbon cable to X carriage PCB 13:21 - Install ribbon cable guide X carriage guide 14:20 - Install X carriage to rod 15:13 - Install timing belt 16:14 - Install extruder ribbon cable to main board 17:10 - Tighten loose ground screws 17:35 - Install Smart Extruder 18:19 - Install exisiting Extruder 18:56 - Install filament guide 19:06 - Screw back the screw that how the extruder 19:26 - Install back the power cable 19:48 - Last of all install X carriage ribbon cable to main board What you need Dual Material Kit (RBX01-DMKIT-SP2) Tools List, Parts List, and etc Tools Required: 1.5 mm Hex Driver (Allen Wrench) 2.0 mm Hex Driver (Allen Wrench) 2.5 mm Hex Driver (Allen Wrench) 4.0 mm Hex Driver (Allen Wrench) T6 Torx Driver or (1) Size 0 Philips screwdriver – depends on printer Extruder Box: 1. Bowden Tube - includes barb and crimp 2. 200mm length of PTFE Tube 3. 140mm length of PTFE Tube 4. Extruder FFC Cable 5. CT3x8mm Securing Screw 6. RBX01-X2 - Flexible Compatible Extruder - includes Bowden Locking Ring DualMaterial Head Box: 7. RBX01-DM - Dual Material Head 8. 10x Bed Wipes (not pictured)
