Performance Max Throughput PTP/PTMP: 700 Mbps IP (866 Mbps PHY) Wireless Protocols WiFi Interop Mimosa SRS Modes PTMP Client PTP Backhaul Radio MIMO & Modulation 2x2:2 MIMO OFDM up to 256 QAM Bandwidth* 20/40/80 MHz channels tunable to 5 MHz increments for Mimosa SRS; Tunable to standard WiFi channels for WiFi Interop Frequency Range PTMP: 4900-6400 MHz*** PTP: 4900-6400 MHz Restricted by country of operation new US/FCC 5600-5650 MHz support FCC DFS (U-NII-2a, U-NII-2c) availability pending certification Max Output Power 27 dBm Sensitivity ( MCS 0 ) -87 dBm @ 80 MHz -90 dBm @ 40 MHz -93 dBm @ 20 MHz Power Max Power Consumption 9.2 W System Power Method Passive PoE (24-56 VDC) PoE Power Supply Passive POE compliant, 48-56 V Power over Ethernet supply (Not Included) Physical Dimensions Depth 44 mm (1.73") Width 65 mm (2.56") Height 188.4 mm (7.42") Weight 295 grams (10.4 oz) Mounting Single pole strap Connector Type RP-SMA (x2) Environmental Outdoor Ingress Protection Rating IP55 Operating Temperature -40°C to +55°C (-40°F to 131°F) Operating Humidity 5 to 100% condensing Operating Altitude 4420 m (14501') maximum Shock & Vibration ETS 300-019-2-4 class 4M5 Features Gigabit Ethernet 10/100/1000-BASE-T Management Services Mimosa cloud monitoring and management, SNMPv2 & Syslog legacy monitoring, HTTPS, HTML 5 based Web UI Smart Spectrum Management Active scan monitors/logs ongoing RF interference across channels (no service impact) Dynamic auto-optimization of channel and bandwidth use Security WPA2 + Mimosa 802.1x Client** QoS Supports 4 pre-configured QoS levels Regulatory + Compliance Approvals FCC Part 15.407 and Part 90Y, IC RSS210, CE, ETSI 301 893/302 502 Other National Regulations RoHS Compliance Yes Safety UL/EC/EN/ 60950-1 + CSA-22.2 4.9 GHz uses 20 MHz channel widths (US only, regulations vary by region) ** Enabled in future software release *** Extended frequency, above 6.2 GHz, requires use of A5/A5c access point with P/N 100-000xx-01
