LSM6DSOX + Raspberry Pi Pico 2 + SPI: Motion Sensor Tutorial (SPI Setup + Code Walkthrough)

🌀 LSM6DSOX (IMU) + Raspberry Pi Pico 2 | SPI Walkthrough, C/C++ Code & Datasheet Deep Dive In this video, I walk you through how to interface the LSM6DSOX 6-axis IMU with the Raspberry Pi Pico 2 using SPI communication. We go step-by-step through my C/C++ code, referencing the LSM6DSOX datasheet along the way so you understand exactly what each register and setting does. To make things even clearer, I use my Digilent Logic Analyzer to capture and visualize the SPI transactions in real time—so you can see what’s really happening on the wires. Whether you're just getting started with embedded systems or diving deeper into SPI protocol and sensor integration, this is a practical walkthrough to help you understand both the code and the hardware-level details. 📌 What You’ll Learn: Setting up SPI on the Raspberry Pi Pico Initializing and configuring the LSM6DSOX Reading accelerometer and gyroscope data How to interpret register settings from the datasheet Analyzing SPI data using a logic analyzer 🔧 Tools Used: Raspberry Pi Pico 2: https://www.adafruit.com/product/6328 ST LSM6DSOX IMU: https://www.adafruit.com/product/4438... Digilent Logic Analyzer + WaveForms: https://digilent.com/shop/analog-disc... C/C++ (Pico SDK): https://datasheets.raspberrypi.com/pi... LSM6DSOX Datasheet: https://www.st.com/resource/en/datash... 👨‍💻 Code Repo: https://github.com/code-on-the-edge/r... Chapters: 0:00 Intro 0:39 Setup / Create New Project 1:46 Including Libraries 2:08 main() Function 2:25 SPI Defines 4:05 SPI Initializtation Function 6:28 SPI Read Function 10:25 SPI Write Function 12:42 LSM6DSOX Configuration Registers 13:56 WHO_AM_I Register 14:37 Breadboard Connections 16:53 Compile Project 17:22 How to Flash Pico with Program 18:15 Minicom installation & Set up 18:47 Fixing 2 bugs 19:18 Analyzing WHO_AM_I Register SPI Transaction 20:22 Accelerometer Control Register 1, CTRL1_XL 21:47 Gyroscope Control Register 2, CTRL2_G 22:52 Control Register 3 23:30 Analyzing Control Register SPI Transaction 25:28 Gyroscope & Accelerometer Registers in Datasheet 26:43 imu_read() Function 27:07 Reading Raw Gyroscope & Accelerometer Data 29:58 Convert Raw Data into int16_t 31:00 Convert Raw int16_t Data into Physical Units 33:36 Analyzing Gyroscope & Accelerometer Data on Serial Terminal 34:02 Analyzing Earth Gravitational Force on Accelerometer 34:43 Analyzing Rotational Speed on Gyroscope 35:52 Shaking LSM6DSOX Sensor 36:15 Outro #RaspberryPiPico #LSM6DSOX #EmbeddedSystems #SPI #IMU #LogicAnalyzer #Digilent #cpp #SensorFusion #CodeOnTheEdge #cprogramming
