C-More HMI Do-More PLC Modbus Tags - Screen Navigation Dev Now!

Previously, we put our first program (Video) into the C-More Micro HMI Panel using the C-More Micro programming software. The Do-More Designer Simulator was used with a modified Start-Stop Jog Circuit, so we can use our HMI screen to control both the output and the PLC inputs. This communication was done via Ethernet with the Modbus TCP protocol. We will now look at PLC-to-Panel and Panel-to-PLC communications. This will allow us to control the panel's screen page number, beeper, and backlight from the PLC. We will also receive notifications of the same, as well as key-press information from the HMI panel. Let's get started. More information can be obtained on our Website. This includes all of the links mentioned in this video. https://accautomation.ca/c-more-micro... 00:00 C-More Micro First Program Part 2 00:55 Panel to PLC / PLC to Panel Communication 02:45 C-More Setup Panel to/from PLC 07:33 C-More Project Transfer and Testing 08:00 Do-More Monitor Data 09:45 C-More Change Page from PLC 10:42 C-More Beep Control 11:03 C-More Background Color Previously, we have discussed the following in our C-More Micro HMI Panel: System Hardware http://accautomation.ca/c-more-micro-... Unboxing and Review Video    • C-More Micro HMI Hardware Unboxing and Review   Installing the Software http://accautomation.ca/c-more-micro-... Installing the Software Video    • C-More Micro HMI Programming Tool Download...   Update Automation Direct Software C More Micro Software Video    • Update Automation Direct Software C-More M...   System Setup Screens http://accautomation.ca/c-more-micro-... System Setup Screens Video    • C-More Micro HMI System Setup Screens   First Program http://accautomation.ca/c-more-micro-... First Program Video    • Master C-More Micro HMI: Build Your First ...   There are several reasons that we are using the EA3-T4CL C-More Micro Panel. Here are a few: • Touch screen display • Free downloadable programming software • 482 x 272-pixel display (WQVGA) with up to 40 lines by 80 characters of text and graphics • 32K colors • 14MB memory • Built-in USB type Micro-B programming port • Built-in RJ45 Ethernet Port • Built-in 15-pin serial communications port • Built-in RJ12 serial communications port • Built-in Alarm Control setup that activates beep, back-light flash, customized alarm banner, and red LED blinking • 0 to 50 °C (32 to 122 °F) operating temperature range (IEC 60068-2-14) • NEMA 4/4X, IP65 compliant when mounted correctly, indoor use only • UL, cUL & CE agency approvals • 2-year warranty from date of purchase Regards, Garry ACC Automation http://www.accautomation.ca
