I Built a Speaker Cabinet Designed by AI – Full DIY Process

In this video, I build a custom bass reflex speaker enclosure entirely designed by AI – from the internal volume and port tuning to the overall dimensions for optimal performance! At the heart of this project is the excellent Visaton FR 10 HM – a compact 4" full-range driver 4 ohm version, known for its clear highs thanks to the integrated tweeter cone, solid midrange, and surprisingly punchy bass when paired with the right cabinet. I added custom 3D-printed anti-vibration feet to isolate the speaker from the surface, reducing unwanted resonances and improving clarity. Plus, a precisely tuned bass reflex port (also 3D-printable) for extended low-end response. Watch the full step-by-step build: woodworking, assembly, driver installation, wiring, and final sound test. The results are seriously impressive for such a small speaker! If you love DIY audio, AI experiments, or high-quality sound on a budget, hit that LIKE button and SUBSCRIBE for more projects! #DIYspeaker #AIdesigned #Visaton #FullrangeSpeaker #BassReflex Project Overview • Driver: Visaton FR 10 HM - 4 Ω (4-inch full-range, direct connection – no crossover). • Enclosure type: Bass reflex. • External dimensions: 170 mm width × 250 mm depth × 350 mm height. • Internal net volume: ≈10 litres (ideal for this driver). • Materials: ◦ Body (sides, top, bottom, rear): 15 mm MDF. ◦ Front baffle: 15 mm plywood/multilayer (poplar or birch). • Bass reflex port: Rear panel, centred low. Diameter: 40 mm, length: 15 cm (flared on both ends recommended to minimise turbulence). Tuning frequency Fb ≈75 Hz → useful bass extension down to ~70 Hz in-room. • Damping: ◦ 5 mm car damping mat applied to internal panel surfaces (including rear of baffle). ◦ Dacron, polyfill or similar polyester filling (80 g total, loosely distributed). • Driver mounting: ◦ Preferably flush mount (rebated 2-4 mm deep for perfect alignment). ◦ Alternative: surface mount (slightly protruding). ◦ Position: centred horizontally; centre of driver 135 mm from the top edge of the baffle. 0:00 AI Designed Speaker – Why This Project Is Crazy 0:46 Visaton FR 10 HM Driver – Specs & Why It's Special 0:55 How AI Calculated the Perfect Bass Reflex Box 1:23 Let’s start – Cutting the Panels 2:14 Assembling the Baffel – plywood and solid wood 2:42 Cabinet and Baffle holes 4:03 Assembling the Cabinet - wooden biscuits and glue 4:26 Damping & Internal Filling – No Resonances 4:59 Sanding- fix imperfections 5:19 Prepare surfaces - Trasparent Primer 5:36 Colouring process – paint cabinet 5:50 Port reflex - install 6:15 Driver Mounting & Wiring – Flush Mount Tips 6:35 Installing the 3D Printed Anti-Vibration Feet 6:45 Final Sound Test – Real Bass from a Tiny Box! Free download links for the 3D print files: Anti-vibration feet for speakers: https://makerworld.com/it/models/2064... Bass reflex pipe: https://makerworld.com/it/models/2180... ----- For Sponsorships, Collaborations or Brand Deals: -----Please contact me here → diyzone0101@gmail.com Affiliated link: AIYIMA Audio T9 https://s.click.aliexpress.com/e/_c4m... HiFi OCC Speaker Cable  https://s.click.aliexpress.com/e/_c3B... Sheets Car Sound Deadener Heat Insulation Mat  https://s.click.aliexpress.com/e/_c3r... Canon in D Major di Kevin MacLeod è un brano concesso in uso tramite licenza Creative Commons Attribution 4.0. https://creativecommons.org/licenses/... Fonte: http://incompetech.com/music/royalty-... Artista: http://incompetech.com/
