Linear Scale ТЕА5767 FM Radio on ili9341 TFT Display

This project is sponsored by PCBWAY https://www.pcbway.com/ This time I will present you how to make a simple FM Radio with a beautiful retro linear scale. The idea for the project was taken from the Volos Projects channel, where is presented the code that was specially made for the LilyGO T-Embed device, which has a TFT screen with a resolution of 320 x 170 pixels. I just adapted the code for the ILI9341 TFT Display which has a resolution of 320×240 pixels powered by an ESP32 dev kit module. As you can see, the device is very simple to build and consists of several components: ESP32 dev kit board ILI9341 TFT Display 2.8 inch TEA5767 Radio module Rotary encoder with push button Small D-class audio amplifier board and Speaker In order for the code to run without errors, you should use the libraries provided with the code, as they have been modified (TFT_eSPI) specifically for this project. Detailed instructions, Schematic, and code at: https://www.hackster.io/mircemk/linea... If you like my job buy me a coffee: https://ko-fi.com/mircemk If you are interested in this area, look at the Playlist with all my DIY Radios at:    • All My DIY Radio Receivers   Visit my Youtube Channel for more Projects , DIY and How To Make videos:    / mirkopavleskimk   by mircemk SUBSCRIBE LIKE AND SHARE !!!! Thanks for your Support ! #TEA5767 #electronics #Radio #PCBWay
