High-performance wedge anchor | W-FAZ Pro

High-performance wedge anchor for high loads in cracked and uncracked concrete, zinc-plated steel Highest load values at low spacing and edge distances Extra-large effective anchorage depths maximise the already high load values per anchor Quick installation with fewer reinforcement hits Extra-small effective anchorage depths minimise the drilling and embedment time Economical and flexible application Freely selectable embedment depth allows optimum utilisation of the anchors depending on the embedment depth and application Minimal edge distances and spacing Allows for fixings close to edges, small anchor plates and installation in thin concrete parts For earthquake-proof construction High performance under seismic action, seismic performance categories C1 and C2 Proof of Performance European Technical Assessment ETA-20/0229 for individual fixing point, option 1, cracked and uncracked concrete: Static or quasi-static action (M8-M16) Seismic action, performance category C1 and C2 (M8-M16) Fire resistance R30, R60, R90, R120 Load-bearing behaviour and fire resistance (uniform temperature curve) - expert report no. GS 6.1/20-018-1: Fire duration 180 minutes (M8-M16) Swiss Federal Office for Civil Protection (Bundesamt für Bevölkerungsschutz, BABS) - Approval for shock testing BZS D 20-602 Use in Swiss civil protection buildings (M8-M16, from standard anchorage depth hef,std) Shop now: https://eshop.wurth.co.uk/Fixanchor-W... Find 28,000+ more quality products on our e-Shop! Click here to sign up now: https://fal.cn/3uxRI
