4- How to use Application Configuration in PCM600?

In this video you will get an overview the interface and most used features of Application Configuration in PCM600. This video focuses in on the general functionalities of Application Configuration. There are separate videos for more specific applications and product-focused examples. PCM600 is a common free tool for configuring and managing ABB protection and control products. More information about the tool and download links can be found the PCM600 product page: https://new.abb.com/medium-voltage/di... Please refer to the list of contents below for direct access. Contents: 00:15 How to open application configuration 00:54 Interface overview 01:12 Creating a new main application 01:54 Inserting a function block 03:08 Adding variables 03:56 Adding binary input 04:30 Creating connections between elements with a line 04:50 Function block coloring difference to indicate that all necessary connections have been created 05:35 Connecting variables to the existing logic 06:13 “Go to Partner” feature 06:25 “Find and Replace” feature 06:50 Inserting binary output 08:00 Applying changes to the relay by using “Write to IED...” 08:22 Working in online mode 09: 06 Changing naming style (IEC 61850 and ANSI)
