Portable Oscilloscope Webinar Series Part 1: Basic Theory

http://bit.ly/2RQHb1x In this video, get an in-depth view of how portable oscilloscopes work, the fundamentals of capturing and analyzing waveforms using an oscilloscope and understand the processes used to aid in troubleshooting electrical/electronic signals. The Fluke ScopeMete®r 190 Series II combines the highest safety ratings and rugged portability with the high performance of a bench oscilloscope. Designed for plant maintenance engineers and technicians, these tough ScopeMeter test tools go into harsh, dirty, and hazardous industrial conditions to test everything from microelectronics to power electronics applications. The 190 Series II is the one test tool you will reach for to tackle just about any troubleshooting task. They include a multimeter, TrendPlot™ and ScopeRecord™ roll paperless recorder modes and hands free operation with Connect-and-View™ triggering, and much more: • Four electrically isolated inputs • CAT III 1000 V / CAT IV 600 V safety rated • 200 MHz bandwidth model • 2.5 GS/s • Deep memory: 10,000 samples per channel waveform capture so you can zoom in on the details • Advanced automatic measurements, power (Vpwm, VA, W, PF) and time (mAs, V/s, w/s) • Connect-and-View continuous auto-trigger, single shot, pulse width, and video triggering • ScopeRecord roll mode, capture waveform sample data for up to 48 hours • TrendPlot, trend measurement readings for up to 22 days For more information about Fluke 190 Series II Handheld Oscilloscopes, visit the Fluke website here: http://bit.ly/2RQHb1x
