Barrier Reef Pools Perth Western Australia - Pencil Compaction

Pencil compaction. An electric driven flexi drive unit is used connected to a two metre vibrating shaft and a high flow water hose. We penetrate the sand between the pool back to natural ground, this continues all the way around the pool ensuring the sand is fully compacted to the depth of the excavation. The pencil compactor is also used to penetrate under steps and ledges around the pool to fill all voids and cavities in the area. This generally takes approximately two hours and once completed the area is instantly firm. Most importantly, this whole process is carried out by our own highly trained installation team to ensure the pool is still level and there is no damage to the plumbing around the pool once completed. Once the final levels on the pool have been checked to our company's high standard, the concrete pool footing is the final stage of the pool construction process. Form work is set out around the pool and two rows of steel bar are tied into the pool shell at specialised points for additional reinforcement. The concrete is then poured around the area which is generally 350mm in width and 150mm in depth (This is the same depth as most house slabs). The concrete is levelled between 10-20mm under the top of the pool to ensure maximum paving bond can be applied to every paver. This preparation and process is critical to ensure the paving around the pool area never varies or weakens. http://www.barrierreefpools.com.au/
